Custom-made Radial Flux BLDC Micromotors
Mirmex's groundbreaking technology revolutionizes traditional BLDC motors by getting rid of the constraints historically associated with wire-based motor windings. This innovation paves the way for novel radial flux electric motors, shaping the future of miniature actuators.
Custom-made Radial Flux BLDC Micromotors
The Mirmex brushless slotless DC micromotors offer superior performance and unparalleled adaptability, regardless of their shape or length.
With zero-cogging and unique printed winding tolopologies, your motorized system can be easily upgraded to a level of performance beyond elite Swiss applications.
![Mirmex Motor | Radial Flux BLDC Micromotors Mirmex Motor | Radial Flux BLDC Micromotors](http://mrmx-10980.kxcdn.com/web/image/52544-9087d693/Radial%20Flux%20Micro%20Motor.png)
3 - 80
Diameter [mm]
2 - 120
Length [mm]
1000
Power (up to) [W]
500
Torque (up to) [mNm]
120 000
Speed (up to) [rpm]
Benefits
![Mirmex Motor | more compact & lighter Mirmex Motor | more compact & lighter](http://mrmx-10980.kxcdn.com/web/image/52598-f3bf6988/PICTO%20-%20more%20compact%20-%2020x20cm%20-%20300%20DPI%20-%20revised.png)
More Compact
Compared to the competition and at equal performance, the Mirmex micromotors are up to 50% smaller.
![Mirmex Motor | best performance density Mirmex Motor | best performance density](http://mrmx-10980.kxcdn.com/web/image/52599-1c46ca06/PICTO%20-%20torque%20vs%20speed%20-%2020x20cm%20-%20300%20DPI.png)
Best Performance Density
Whatever the application, the Mirmex windings provide a superior copper fill-factor, enhancing motor performance within a specified volume unit.
![Mirmex Motor | custom-made Mirmex Motor | custom-made](http://mrmx-10980.kxcdn.com/web/image/50937-47dff955/PICTO%20-%20infinite%20flexibility.png)
Custom Made
Diameter, length, speed, voltage…
You have total design freedom.
No more compromise because of limitations dictated by Swiss catalogues, no matter how thick.
![Mirmex Motor | easy prototyping Mirmex Motor | easy prototyping](http://mrmx-10980.kxcdn.com/web/image/50925-fb5d7048/PICTO%20-%20production%20ease%20-%20very%20small.png)
Easy Prototyping
Getting custom-made Mirmex micromotors is painless, quick and much more affordable.
10x faster prototype manufacturing.
![Mirmex Motor | consistent performances Mirmex Motor | consistent performances](http://mrmx-10980.kxcdn.com/web/image/50928-c4ed66f3/PICTO%20-%20consistent%20performances%20-%20very%20small.png)
Consistent Performances
Our manufacturing provides a higher degree of repeatability, up to each copper fiber.
This leads to higher robustness and more homogeneous product performances.
![Mirmex Motor | better thermal behavior Mirmex Motor | better thermal behavior](http://mrmx-10980.kxcdn.com/web/image/50924-d8834484/PICTO%20-%20better%20control%20thermal%20aspect%20-%20very%20small.png)
Better Thermal Behavior
A higher fill-factor and the ability to balance all possible sources of losses (thermal, Eddy…) enable to divide thermal losses by a significant factor.
![Mirmex Motor | more sustainable Mirmex Motor | more sustainable](http://mrmx-10980.kxcdn.com/web/image/50927-432ad6b1/PICTO%20-%20sustainable%20concept%20-%20very%20small.png)
More Sustainable
The Mirmex technology optimizes micro-motors and make them use less energy.
Up to less than 45% raw materials are also required.
![Mirmex Motor | unique coil topologies Mirmex Motor | unique coil topologies](http://mrmx-10980.kxcdn.com/web/image/50926-41ee4fcd/PICTO%20-%20unique%20topology%20patterns%20-%20very%20small.png)
Unique Coil Topologies
Mirmex winding topologies are unachievable with conventional wire-winding methods.
They provide unmatched levels of performance and efficiency.
![Mirmex Motor | autoclavable Mirmex Motor | autoclavable](http://mrmx-10980.kxcdn.com/web/image/50918-9c5d8367/PICTO%20-%20autoclavable%20-%20very%20small%20white.png)
Autoclavable
Mirmex micromotors are designed to endure hundreds of autoclave cycles and can be used in harsh environments, from intra-body to industrial to sterilization.
Radial Flux BLDC Micromotors Application Examples
Medical Power Tools Motorization
Diameter: 18.5 mm
Length: 37 mm
Speed: 80.000 rpm
Power: 75 W
Torque: 10 mNm
Efficiency: 93%
Key Features
- Thermally optimized - Longer running time before overheating.
- More compact and lighter - Easier to integrate in hand pieces.
- Higher Torque - More performant for demanding bone surgeries.
Space Equipment Actuators
Diameter: 20 mm
Length: 32 mm
Speed: 10.000 rpm
Power: 100 W
Torque: 100 mNm
Key Features
- High Torque - Safe operating. Simplified gearbox.
- Lighter - Reduction of equipment weight.
- Robustness and precision - Better longevity with greater effectivness.
Cobot Actuator
Diameter: 43 mm
Length: 30 mm
Speed: 1500 rpm
Power: 30 W
Torque: 190 mNm
Key Features
- More Dynamic - Makes the equipment more reactive and improves takt-time.
- Smaller Motor Size - Easier to integrate in compact equipment.
- Zero cogging, Linear Driveability - Precision in all movements.
Our Motor Development Flow...
![Mirmex Motor | Scope & Modelling Mirmex Motor | Scope & Modelling](http://mrmx-10980.kxcdn.com/web/image/52579-b8fbeec7/STEP%201.png)
Scope & Modeling
![Mirmex Motor | Prototyping Mirmex Motor | Prototyping](http://mrmx-10980.kxcdn.com/web/image/52581-de4446b4/STEP%202.png)
Prototyping
![Mirmex Motor | Testing & Fine Tuning Mirmex Motor | Testing & Fine Tuning](http://mrmx-10980.kxcdn.com/web/image/52582-33ddc2af/STEP%203.png)
Testing & Fine Tuning
![Mirmex Motor | Mass Production Mirmex Motor | Mass Production](http://mrmx-10980.kxcdn.com/web/image/52580-5db031af/STEP%204.png)
Mass Production
Customize your own affordable motor in a few weeks
